Heavy Duty Hydraulic Mooring Winch
● Tsis muaj lub nruas: Ib leeg lossis ob npaug
● Tsav hom: Hydraulic
● rub quab yuam: 5KN ~ 600KN
● Ua haujlwm ceev: 6m / min ~ 15m / min
● Cov hlua muaj peev xwm: 100m ~ 1500m
● Txoj kab uas hla: ø8mm ~ ø64mm
Hauj lwm lawm
Peb tuaj yeem muab hydraulic mooring winch thiab hluav taws xob mooring winch, feem ntau hydraulic winches muaj peev xwm loj dua li hluav taws xob winches thiab hydraulic winches tau txais los ntawm cov nkoj loj ntau dua li cov hluav taws xob winches; Qee lub sij hawm, lub mooring winch kuj tuaj yeem muaj lub zog ua ke los tsav lub winch thaum lub sijhawm ua haujlwm.
Nta
Compact tsim& kev ntseeg siab yooj yim rau nruab siab pib& ua hauj lwm efficiency
Txhim khu kev ua haujlwm nrog suab nrov me ntsis
Kev saib xyuas qis txo koj txoj kev ntxhov siab
Main specification ntawm hydraulic winch
Qauv | mooring nruas | Lub cev muaj zog | ||
Rated rub | ceev | nruas muaj peev xwm | ||
(Kn) | (m / min) | (mm × m) | (kW) | |
YB 30 | 30 | 15 | 50×150 | 18.5 |
YB 40 | 40 | 15 | 50×150 | 18.5 |
YB 50 | 50 | 15 | 60×150 | 22 |
YB 60 | 60 | 15 | 70×160 | 30 |
YB 70 | 70 | 15 | 70×160 | 30 |
YB 80 | 80 | 15 | 80×180 | 37 |
YB 100 | 100 | 15 | 80×180 | 37 |
YB 125 | 125 | 15 | 80×200 | 55 |
YB 150 | 150 | 15 | 80×200 | 75 |
YB 200 | 200 | 15 | 100×220 | 90 |
YB 250 | 250 | 15 | 100×220 | 110 |
Cim npe nrov: hnyav luag hauj lwm hydraulic mooring winch, Tuam Tshoj, lwm tus neeg, customized, pheej yig
