6x19 FC Tubrog nkoj Hlau Hlau Hlua
1. Hom: Ci lossis Galvanized
2. Txoj kab uas hla: 2mm txog 60mm
3. Ntawv pov thawj hauv chav kawm: CCS, ABS 、 BV 、 DNV-GL 、 LR 、 KR 、 RINA
4. Qauv: ntau yam
Hauj lwm lawm
Tus qauv 6x19 + FC marine steel hlau ropemeans 6strand*19 xaim nrog hlau nrog cov tub ntxhais fiber
Peb tuaj yeem muab hom hlua hlau raws li tus qauv GB, ISO, DIN, JIS, BS thiab lwm yam uas siv dav hauv nkoj, ntug dej hiav txwv thiab lwm yam kev lag luam.
6x19 +FCwire hlua nta
1.Type: Ci lossis Galvanized
2.Diameter: 2mm txog 60mm
3.Qhov ntawv pov thawj: CCS, ABS, BV, DNV-GL, LR, KR, RINA
4.Qhov: ntau yam
5.Usage hauv marine: mooring, towing
6.Original: Tuam Tshoj
6x19+ FC xaim hlua Specification
| Nominal txoj kab uas hla | Kwv yees qhov hnyav | Norminal T/S (N/hli 2) | |||||||||
| 1570 | 1670 | 1770 | 1870 | ||||||||
| hli | Ntiv | Kg/100m | Min B/L (KN) | ||||||||
| FC | IWR | FC | IWR | FC | IWR | FC | IWR | FC | IWR | ||
| 6 | 1/4 | 12.5 | 13.7 | 17.3 | 18.7 | 18.4 | 19.9 | 19.5 | 21.1 | 20.6 | 22.3 |
| 7 | 9/32 | 17 | 18.7 | 23.6 | 25.5 | 25.1 | 27.1 | 26.6 | 28.7 | 28.1 | 30.4 |
| 8 | 5/6 | 22.1 | 24.4 | 30.8 | 33.3 | 32.8 | 35.4 | 34.7 | 37.6 | 36.7 | 39.7 |
| 9 | 3/8 | 28 | 30.9 | 39 | 42.2 | 41.5 | 44.9 | 44 | 47.5 | 46.5 | 50.2 |
| 10 | 13/32 | 34.6 | 38.1 | 48.1 | 52.1 | 51.2 | 55.4 | 54.3 | 58.7 | 57.4 | 62 |
| 11 | 7/16 | 41.9 | 46.1 | 58.3 | 63 | 62 | 67 | 65.7 | 71.1 | 69.4 | 75.1 |
| 12 | 1/2 | 49.8 | 54.9 | 69.4 | 75 | 73.8 | 79.8 | 78.2 | 84.6 | 82.6 | 89.4 |
| 13 | 1/2 | 58.5 | 64.4 | 81.4 | 88 | 86.6 | 93.7 | 91.8 | 99.3 | 97 | 104 |
| 14 | 9/16 | 67.8 | 74.7 | 94.4 | 102 | 100 | 108 | 106 | 115 | 112 | 121 |
| 16 | 5/8 | 88.6 | 97.5 | 123 | 133 | 131 | 141 | 139 | 150 | 146 | 158 |
| 18 | 11/16 | 112 | 123 | 156 | 168 | 166 | 179 | 176 | 190 | 186 | 201 |
| 20 | 13/16 | 138 | 152 | 192 | 208 | 205 | 221 | 217 | 235 | 229 | 248 |
| 22 | 7/8 | 167 | 184 | 233 | 252 | 248 | 268 | 263 | 284 | 277 | 300 |
| 24 | 15/16 | 199 | 219 | 277 | 300 | 295 | 319 | 312 | 338 | 330 | 357 |
| 26 | 1 | 234 | 258 | 325 | 352 | 346 | 374 | 367 | 397 | 388 | 419 |
| 28 | 1（1/8） | 271 | 299 | 377 | 408 | 401 | 434 | 426 | 460 | 450 | 486 |
| 30 | 1（3/16） | 311 | 343 | 433 | 469 | 461 | 498 | 489 | 528 | 516 | 558 |
| 32 | 1（1/14） | 354 | 390 | 493 | 533 | 524 | 567.0.0 | 556 | 601 | 587 | 635 |
| 34 | 1(5/6) | 400 | 440 | 557 | 602 | 592 | 640 | 628 | 679 | 663 | 717 |
| 36 | 1（2/5） | 448 | 494 | 624 | 675 | 664 | 718 | 704 | 761 | 744 | 804 |
| 38 | 1（1/2） | 500 | 550 | 695 | 752 | 740 | 800 | 784 | 848 | 828 | 896 |
| 40 | 1-19/32 | 554 | 610 | 771 | 833 | 820 | 887 | 869 | 840 | 918 | 993 |
