Marine Screw Type Compressor

● Series: ntsia hlau hom compressor GRF
● Muaj peev xwm ntau: 0.8 txog 40 m3 / h
● Siab: 8 ~ 10bar
● 2-theem cua txias
● Daim ntawv pov thawj; CCS

Xa kev nug

Hauj lwm lawm

Marine ntsia hlau hom cua compressor yog tsim rau txhua yam ntawm me me thiab nruab nrab ships, xws li destroyers, patrol ships, yachts, tsaws nkoj thiab hais txog.

Main Feature

1. Cov khoom tseem ceeb thiab cov qauv yog raug kho los ntawm cov txheej txheem tshwj xeeb. Nws muaj kev tiv thaiv zoo rau rot thiab turbidity, tsis tshua muaj zog, tsis tshua muaj suab nrov, compact qauv, me me ntim, lub teeb yuag, zoo nkauj tsos, du thiab yooj yim installation. Nws yog tsuas yog siv rau nkoj.

2. Compact qauv, me me ntim, tsis tshua muaj suab nrov, me me vibration, me me zog noj, ruaj khov thiab txhim khu kev qha lag luam.

3. Nws muaj kev tswj tsis siv neeg thiab kev tiv thaiv kev ua haujlwm thiab cov khoom siv hauv German tuaj yeem tau txais kev pom zoo ntawm hom nkoj.

Parameter

Marine ntsia hlau hom cua compressor

Qauv	tshem tawm / tso pa tawm siab m3 / min / bar		Lub zog (kw)	Qhov hnyav (kg)	Qhov hluav taws xob txoj kab uas hla
GRF-30C	3.4-8	3.1-10	22	680	G1
GRF-50C	6.4-8	5.6-10	37	950	G1½
GRF-75C	10.0-8	8.5-10	55	1550	DN 50
GRF-100C	12.4-8	11.1-10	75	1800	DN 50
GRF-120C	15.3-8	14.0-10	90	2250	DN 65
GRF-150C	20.0-8	17.5-10	110	2250	DN 65
GRF-175C	22.5-8	21.0-10	132	2800	DN 80
GRF-220C	26.7-8	24.7-10	160	3000	DN 80
GRF-250C	30.0-8	28.8-10	185	3200	DN 80
