Marine Medium Pressure Cua Compressor

● Series: HC
● Muaj peev xwm ntau: 54 txog 190 m3 / h
● Siab: 30bar
● 2-theem dej txias

Hauj lwm lawm

Cua compressors ua ntau yam haujlwm hauv marine ib puag ncig. Nws tuaj yeem siv los sau compressed cua lub tog raj kheej. Nws tuaj yeem siv los ua cov compressors tseem ceeb uas pib rau lub cav, nws tseem tuaj yeem siv rau ntawm lub lawj uas tuaj yeem ua haujlwm ntau yam ntawm cov cuab yeej siv hluav taws xob pneumatic, thiab tseem muaj cov haujlwm ntsig txog kev huv thiab huv.

Main Technical Parameter

1. HC Series Marine Cua Compressor (Tsis muaj peev xwm)

Lub npe	Cua Compressor
Hom	Vertical, dej txias, ob theem compression
Qauv No.	HC-25/30	HC-65/30	HC-69/30	HC-72/30	HC-82/30	HC-90/30
Muaj peev xwm m3/h	54	65	69	72	82	90
Tshem tawm siab Mpa	3	3	3	3	3	3
Lub cev muaj zog kw	12.5	15.2	15.5	16.5	19	20.5
Kev sib hloov ntsuas r/min	730	870	730	960	870	960
Kev siv dej txias m3/h	1.0-1.4
Lubrication	Forced lubrication los ntawm iav twj tso kua mis
Txoj kev tsav tsheb	Kev sib txuas ncaj qha
Lub cev muaj zog
Qauv	Y200L-8-H	Y225S-8-H	Y225S-8-H	Y200L1-6-H	Y225M-8-H	Y200L2-6-H
Lub zog kw	15	18.5	18.5	18.5	22	22
Lub zog v	380	440	380	380	440	380
Zaus Hz	50	60	50	50	60	50
Qib tiv thaiv	IP44
Rwb thaiv tsev chav kawm	B
Nyhav kg	700

2. HC₂Series Marine Cua Compressor (High peev xwm)

Lub npe	Marine Cua Compressor
Hom	Vertical, dej txias, ob theem compression
Qauv No.	HC-137/30		HC-170/30		HC-190/30
Muaj peev xwm m3/h	137		170		190
Tshem tawm siab Mpa	3		3		3
Lub cev muaj zog kw	31		38		41
Kev sib hloov ntsuas r/min	730		870		960
Kev siv dej txias m3/h	1.0-1.4
Lubrication	Forced lubrication los ntawm iav twj tso kua mis
Txoj kev tsav tsheb	Kev sib txuas ncaj qha
Lub cev muaj zog
Qauv	Y280S-8-H	Y280M-8-H		Y280S-6-H
Lub zog kw	36	45		45
Lub zog v	380	440		380
Zaus Hz	50	60		50
Qib tiv thaiv	IP44
Rwb thaiv tsev chav kawm	B
Nyhav kg	1400
